Geosensor–Ringlaser
Technical Description:
Laser Gyroscope for measurement of seismic rotational waves in seismic and geophysical studies.
Technical Data:
| Laser wavelength: | 633 nm | |
| Mirror distance / Area: | Square 1.6 x 1.6 m2 scalable to larger dimensions |
|
| Mirror system: | 4 spherical supermirrors ø25.4mm separate adjustable with a folded lever system in 4 corner boxes made from mineral–epoxy casted material | |
| Vakuum range: | built in a completely UHV compatible design, but running under He–Ne–filling |
Customer & Period:
| Customer: | Technical University Munich | |
| Period of Implementation: | 2002 to 2005 |
